ANYLOAD AN560 Axle Weighing Indicator

The ANYLOAD AN560 is a durable, portable wireless indicator built for axle weighing in challenging field conditions. Equipped with a 4.2″ E-ink display, integrated thermal printer, and connectivity for up to eight scales, it delivers clear readings and efficient operation anywhere. When paired with ANYLOAD AXA Axle Weigh Pads, it supports weigh-in-motion and balancing functions for precise, reliable vehicle weighing.

Contact us with any product-related or implementation-related questions.

$2,776.00

Quantity Price
1 - 9 $2,776.00
10 - 24 $2,637.20
25 - 49 $2,553.92
50 - 99 $2,470.64
100 + $2,359.60
Tacuna Systems Price Match Guarantee

ANYLOAD AN560 Axle Weighing Indicator Features

The ANYLOAD AN560 is a rugged, portable wireless indicator engineered for precise axle weighing in demanding environments. Its 4.2″ E-ink display provides exceptional visibility in any lighting condition, while the integrated thermal printer enables instant, on-site data recording. Supporting wireless connectivity for up to eight scales, the AN560 streamlines multi-axle vehicle weighing with ease. Built-in weigh-in-motion and balancing functions ensure accurate and efficient performance in the field. Compact and reliable, it pairs seamlessly with ANYLOAD AXA Axle Weigh Pads to create a complete, high-performance mobile weighing solution. Trusted by professionals across transportation, logistics, and enforcement applications.

Features:

  • Long-lasting 21700 lithium-ion battery with PCM, approx. 600 hours of operation per charge
  • High-contrast E-ink 4.2″ display with LED front light for excellent visibility in all lighting conditions
  • Supports wireless connection to up to 8 axle pads or scales simultaneously
  • Durable silicon keypad for extended field use and tactile feedback
  • Stores data for up to 1,000 vehicles
  • Zigbee wireless communication on 2.4 GHz ISM band
  • USB-A port for data backup to USB flash drives
  • USB-B port for both charging and virtual COM communication
  • Integrated direct line thermal printer for immediate ticket output
  • IP67 rated rugged housing for outdoor and harsh industrial conditions
  • Compact and portable design (only 6 lb / 2.7kg)

Contact us with any product-related or implementation-related questions.

AXA & AN560 Static Weighing Video

Specifications

ANYLOAD AN560 Axle Weighing Indicator General Specifications

Display E-ink 4.2″ with LED front light
Internal Memory Up to 1000 vehicle records
Maximum Connections Supports up to 8 scales
Protocol Proprietary 802.15.4
Indoor/Outdoor Range 30 / 300 meters
USB-A Port For a USB memory stick
USB-B Port USB VCP interface & charging
Printer Integrated direct line thermal printer
Battery Built-in 21700 Li-ion with PCM
Charger 12VDC, 2A SMPS adapter
( Quick Charge 2.0 / 3.0 compatible)
Operating Time Approx. 600 hours
Operating Temperature -20°C to 60°C
Operating Humidity 85% R.H. (No Condensation)

Technical Documents

AN560 Axle Weighing Indicator Datasheet
AN560 Axle Weighing Indicator Manual
AN560 Axle Weighing Indicator Brochure
