ANYLOAD MH363YH Alloy Steel Mounting Head



The ANYLOAD MH363YH is an alloy steel mounting head for use with the Anyload 363YH/363YS in compression applications.

Quantity Price
1 - 9 $44.00
10 - 24 $41.80
25 - 49 $40.48
50 - 99 $39.16
100 + $37.40
Tacuna Systems Price Match Guarantee
SKU: MH363YH Category: Brand:

ANYLOAD MH363YH Features

The ANYLOAD MH363YH Alloy Steel Mounting Head is a robust and versatile mounting solution designed to complement the Anyload 363YH/363YS. Constructed from high-quality alloy steel, it provides exceptional strength and durability, making it suitable for heavy-duty industrial applications. It provides a stable, sacrificial load point for use in compression applications.

  • Material: Alloy steel
  • Available Rated Capacities: (1-5)t, (10-20)t & 30t.
  • Load Cell Fit: MH363YH-(1-5)t fits 1–5 t load cells; MH363YH-(10-20)t fits 10 t and 20 t load cells; MH363YH-30t fits 30 t load cells
  • Thread: M24X2 for 1–5 t; M36X2 for 10 t and 20 t; M42X2 for 30 t
  • Head Diameter: 27.0 mm (1.06 in) for 1–5 t; 45.0 mm (1.77 in) for 10 t and 20 t; 54.0 mm (2.13 in) for 30 t
  • Head Height: 8.0 mm (0.31 in) for 1–5 t; 22.0 mm (0.87 in) for 10 t and 20 t; 32.0 mm (1.26 in) for 30 t

Available Options: (1-5)t, (10-20)t & 30t.

Please contact us with any product-related questions, including availability of other capacities and options.

Specifications

ANYLOAD MH363YH Specifications

Part Number Load Cell Capacity Head Diameter (C1) Top Spherical Radius (C2) Head Height (H1) Shank Length (H2) Thread (T) Weight Approx. (kg)
MH363YH-(1-5)t 1t, 2t, 3t, 5t 27.0 mm (1.06 in) 85.0 mm (3.35 in) 8.0 mm (0.31 in) 25.0 mm (0.98 in) M24X2 –
MH363YH-(10-20)t 10t, 20t 45.0 mm (1.77 in) 150.0 mm (5.91 in) 22.0 mm (0.87 in) 38.0 mm (1.50 in) M36X2 –
MH363YH-30t 30t 54.0 mm (2.13 in) 180.0 mm (7.09 in) 32.0 mm (1.26 in) 48.0 mm (1.89 in) M42X2 0.97
MH363YH-50t 50t 64.0 mm (2.52 in) 200.0 mm (7.87 in) 42.0 mm (1.65 in) 54.0 mm (2.13 in) M42X2 –
MH363YH-100t 100t 102.0 mm (4.02 in) 300.0 mm (11.81 in) 48.0 mm (1.89 in) 79.0 mm (3.11 in) M70X3 –
MH363YH-(150-200)t 150t, 200t 136.0 mm (5.35 in) 300.0 mm (11.81 in) 60.0 mm (2.36 in) 79.0 mm (3.11 in) M90X3 –
MH363YH-300t 300t 160.0 mm (6.30 in) 500.0 mm (19.69 in) 80.0 mm (3.15 in) 90.0 mm (3.54 in) M120X3 –

Material: Alloy Steel. The letters C1, C2, H1, H2 and T refer to the Mounting Variation 1 drawing in the ANYLOAD 363YH datasheet. The MH363YH-(1-5)t, MH363YH-(10-20)t and MH363YH-30t can be ordered online; contact us for the larger sizes.
