ANYLOAD 101RSLS Stainless Steel S-Beam Load Cell
The ANYLOAD 101RSLS is a durable stainless steel S-beam load cell designed for accurate and reliable weighing in various industrial applications. Its IP40-rated construction ensures water and corrosion resistance, making it ideal for harsh environments.
Other capacities and configurations available – please contact us with any questions
Title | Quantity | Price |
---|---|---|
1-9 | 1 - 9 | 0% $948.00 |
10-24 | 10 - 24 | 5% $900.60 |
25-49 | 25 - 49 | 8% $872.16 |
50-99 | 50 - 99 | 11% $843.72 |
100+ | 100 + | 15% $805.80 |
ANYLOAD 101RSLS Features
The ANYLOAD 101RSLS Stainless Steel S-Beam Load Cell is a high-quality, versatile solution designed for both tension and compression weighing applications. Its robust stainless steel construction provides excellent durability and resistance to corrosion, making it ideal for use in harsh industrial environments. With an IP40 ingress protection rating, it is well-suited for applications that require protection against water and dust, ensuring reliable performance over time. Commonly used in hanging scales, hopper scales, and force measurement systems, this load cell delivers superior accuracy and consistency in demanding applications. Available in various capacities, the ANYLOAD 101RSLS is a reliable choice for industrial weighing and force measurement needs.
- Material: Stainless Steel
- Rated Capacities: 250g, 1lb, 2lb, 3lb, 5lb, 10lb, 25lb, 50lb, 100lb
- Full-Scale Output: 1.0mV/V ± 20% (250g); 2.0mV/V ± 20% (1-100lb)
- Safe Overload: 1000% of full scale (1-25lb); 200% of full scale (50-100lb) for tension only
- IP Rating: IP40
Available Options: 250g, 1lb, 2lb, 3lb, 10lb, 25lb, 50lb & 100lb.
Specifications
ANYLOAD 101RSLS Specifications:
Rated Capacity | 250g, 1lb, 2lb, 3lb, 10lb, 25lb, 50lb, 100lb |
Full-Scale Output | 1.0mV/V ± 20% (250g); 2.0mV/V ± 20% (1-100lb) |
Zero Balance | < ± 0.02mV/V |
Non-linearity | < ± 0.1% |
Repeatability | < ± 0.05% |
Hysteresis Error | < ± 0.1% |
Creep in 30 minutes | < ± 0.1% |
Input Resistance | 350Ω ±10Ω |
Output Resistance | 350Ω ± 5Ω |
Recommended Excitation | 5V (10V Max) |
Insulation Resistance | >5 [50V DC] GΩ |
Nominal Temperature Range | –10°C to 50°C/-14°F to 122°F |
Safe Overload | 1000% of full scale (1-25lb); 200% of full scale (50-100lb) for tension only |
Seal Type | Environmentally Sealed |
IP Rating | IP40 |
Technical Documents
101RSLS S-Beam Load Cell Datasheet |
