ANYLOAD 101AH Alloy Steel S-Beam Load Cell
The ANYLOAD 101AH S-type load cell comes in 1kg-30kg capacities. Its nickel-plated alloy steel construction has an IP65 intrusion rating. It meets leading international safety standards as well.
Other capacities and configurations are available – please contact us to learn more.
| Quantity | Price |
|---|---|
| 1 - 9 | $246.00 |
| 10 - 24 | $233.70 |
| 25 - 49 | $226.32 |
| 50 - 99 | $218.94 |
| 100 + | $209.10 |
ANYLOAD 101AH Features
The Anyload 101AH S-Beam Load Cell is a high-precision force transducer designed for accurate tension and compression measurement in various industrial applications. Built with robust alloy steel construction and protected with an IP65 environmental seal, it ensures durability and reliable performance even in demanding environments. Utilizing advanced strain gauge technology, it offers excellent accuracy with minimal non-linearity, repeatability, and hysteresis errors. This makes it a dependable choice for industrial weighing systems, force monitoring, test equipment, and automation processes where consistent measurement is critical.
- Material: Alloy Steel
- Rated Capacities: 1kg, 2kg, 3kg, 5kg, 10kg, 20kg, 30kg
- Full-Scale Output: 2mV/V ± 10%
- Safe Overload: 150%
- Breaking Overload: 300%
- IP Rating: IP65
- CE, RoHS, and Ex-certified
- ATEX, FM, IECEx available upon request
Available Options: 1kg, 2kg, 5kg, 10kg, 20kg & 30kg.
Please contact us with any product-related questions.
Specifications
101AH Alloy Steel S-Type Load Cell Specifications
| Rated Capacity | 1kg, 2kg, 3kg, 5kg, 10kg, 20kg, 30kg |
| Full Scale Output | 2mV/V ± 10% |
| Zero Balance | ± 0.02mV/V |
| Non-linearity | < ± 0.017% |
| Repeatability | < ± 0.017% |
| Hysteresis Error | < ± 0.017% |
| Creep in 30 minutes | < ± 0.023% |
| Input Resistance | 400Ω ± 20Ω |
| Output Resistance | 350Ω ± 3Ω |
| Recommended Excitation | 10V (15V Maximum) |
| Insulation Resistance | > 2GΩ (50V DC) |
| Temperature Effect on Sensitivity | < ± 0.0012% of Cn/k |
| Temperature Effect on Zero Balance | < ± 0.0040% of Cn/k |
| Compensated Temperature Range | -10°C to 50°C/14°F to 122°F |
| Service Temperature Range | -30°C to 70°C/-20°F to 160°F |
| Storage Temperature Range | -50°C to 85°C/-58°F to 185°F |
| Safe Overload | 150% of full scale |
| Breaking Overload | 300% of full scale |
| Seal Type | Environmentally Sealed |
| IP Rating | IP65 |
Technical Documents
 |
101AH Alloy Steel S-Beam Load Cell Datasheet |
 |
CE Certificate of Conformity RoHS Certificate of Conformity Explosion Protection Certificate of Conformity |
3D Drawing
 |
101AH-(1-30)kg |
|---|
