ANYLOAD 101NH-LE Alloy Steel S-Beam Load Cell
The ANYLOAD 101NH-LE S-beam load cell is available in 5Klb and 10Klb rated capacities. Its nickel-plated alloy steel construction has an IP67 rating. The 101NH-LE meets major standards body requirements for accuracy and safety. This product differs from the similar 101NH load cell in its accuracy specifications (see tab below).
Other capacities and configurations are available – please contact us to learn more.
| Quantity | Price |
|---|---|
| 1 - 9 | $352.00 |
| 10 - 24 | $334.40 |
| 25 - 49 | $323.84 |
| 50 - 99 | $313.28 |
| 100 + | $299.20 |
ANYLOAD 101NH-LE Features
The Anyload 101NH-LE S-Beam Load Cell is a high-precision force transducer engineered for accurate tension and compression measurement in demanding industrial applications. Constructed from durable alloy steel, it delivers exceptional strength, stability, and long-term reliability. Its IP67 sealing ensures excellent protection against dust and moisture, making it suitable for harsh environments. Designed for consistent performance, the load cell provides stable and linear output with minimal non-linearity and repeatability errors. This makes it an ideal solution for industrial weighing systems, force testing equipment, and process monitoring applications.
- Material: Alloy Steel
- Rated Capacities: 5Klb, 10Klb
- Full-Scale Output: 3mV/V ± 0.25%
- Safe Overload: 150%
- Breaking Overload: 300%
- IP Rating: IP67
- NTEP 1:5 000 Class IIIL, Multiple Cell accuracy
- OIML MAA C4.5, Y=14 000 Accuracy
- CE, RoHS, and Ex(NEPSI) certified
- ATEX, FM, and IECEx available upon request
Available Options: LE5Klb & LE10Klb
Please contact us with any product-related questions.
Specifications
ANYLOAD 101NH-LE S-Beam Load Cell Specifications
| Rated Capacities | 5Klb, 10Klb |
| Full Scale Output | 3.0mV/V ± 0.25% |
| Zero Balance | ± 1.0 mV/V |
| Non-linearity | < ± 0.050% |
| Repeatability | < ± 0.03% |
| Hysteresis Error | < ± 0.02% |
| Creep in 30 minutes | < ± 0.02% |
| Input Resistance | 385Ω ± 10Ω |
| Output Resistance | 350Ω ± 3Ω |
| Recommended Excitation | 10V (15V Maximum) |
| Insulation Resistance | > 2GΩ (50V DC) |
| Nominal Temperature Range | –10°C to 50°C/14°F to 122°F |
| Safe Overload | 150% of full scale |
| Breaking Overload | 300% of full scale |
| Seal Type | Environmentally Sealed |
| IP Rating | IP67 |
Technical Documents
Interchangeable Cross Reference
ANYLOAD 101NH-LE Interchangeable Cross Reference
| Manufacturer | Model |
| Vishay Sensortronics | 60001 |
| Rice Lake | 20001 |
| Vishay Celtron | STC |
